Anti Rust Painting Single Acting Dump Trailer Hydraulic Cylinder 3 Stage Type

Anti Rust Painting Single Acting Dump Trailer Hydraulic Cylinder 3 Stage Type

    • Anti Rust Painting Single Acting Dump Trailer Hydraulic Cylinder 3 Stage Type
    • Anti Rust Painting Single Acting Dump Trailer Hydraulic Cylinder 3 Stage Type
  • Anti Rust Painting Single Acting Dump Trailer Hydraulic Cylinder 3 Stage Type

    Product Details:

    Place of Origin: Shandong China
    Brand Name: DALLAST
    Certification: GS CE ISO 9001
    Model Number: Customized

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: negotiation
    Packaging Details: Carton or According to Customer's Require
    Delivery Time: 15-25 days
    Payment Terms: T/T, Western Union, D/A, D/P, L/C
    Supply Ability: 50000 Pieces/Per year
    Contact Now
    Detailed Product Description
    Chrome Plating Thickness: 10-25 μm Trademark: DALLAST
    Work Temperature: Normal Temperature Hydraulic System: Multi-Stage
    Model Number: 3/4/5/6 Stage Usage: Automation And Control
    Painting: Anti Rust Painting Transport Package: Wooden Packing Or Customer′s Needs
    High Light:

    dump truck hydraulic ram


    dump truck hydraulic cylinder

    3 Stage Single Acting Multistage Telescopic Hydraulic Cylinder for Dump Tuck/ Dump Trailer


    Technical Data :

    Product dump truck hydraulic cylinder
    Stroke 50mm-16000mm
    Liner material copper (prolongs the life cycle of cylinder)
    Hydraulic cylinder tube material Carbon steel, Alloy steel, Stainless steel
    Piston Rod Dia 12 - 500 mm (1/2 - 20 inch)
    Hydraulic Cylinder Piston Rod should be hard chrome plated to minimum thickness of 35-55 microns and polished to 0.15 um Ra
    Chome Plated Cr, Ni or Ceramic
    Design Pressure Max 700 bar (10150 PSI)
    Weight Max 60 tons
    Valves SUN (USA),or famous Chinese brand with same quality to PARKER
    Seals Type PARKER (USA), MERKEL (Germany) or NOK (Japan)
    Liner material copper (prolongs the life cycle of cylinder)
    Painting follow with customer requirement or 3-coat marine painting
    Certificate DNV, ABS, Lloyds, BV, GL, KR, NK, RINA, RS and CCS
    Application Engineering machinery (Excavator/ Forklift/ Cranes/ Dump truck,etc), mine, metallurgy, shipping, water conservancy, etc.


    Manufacturing Process:
    DALLAST Hydraulic Ram has suffered rigorous process and inspection to promise the good quality for our customer.

    1. Design Services
    Our design team has experience in cardan shaft relating to product design and development. If you have any needs for your new product or wish to make further improvements, we are here to offer our support.

    2. Product Services
    raw materials → Cutting → Forging →Rough machining →Shot blasting →Heat treatment →Testing →Fashioning →Cleaning→ Assembly→Packing→Shipping

    3. Samples Procedure
    We could develop the sample according to your requirement and amend the sample constantly to meet your need.

    4. Research & Development
    We usually research the new needs of the market and develop the new model when there is new cars in the market.

    5. Quality Control
    Every step should be special test by Professional Staff according to the standard of ISO9001 and TS16949.

    6. Certification

    Should your products require testing and certification to comply with international standards, we can arrange this with independent, fully recognized testing companies such as SGS, Intertec, Bureau Veritas, Lloyd's Register or the testing company of your choice.


    Design Data
    Customer built is the first principle for DALLAST Hydraulic.
    For better knowing your requirement to design the double acting hydraulic cylinder for what you want if you can provide us the following technical parameters:

    1. Bore size

    2. Stroke
    3. Working pressure
    4. Mounting Type

    5. Installation distance




    Q1. What are the same aspects of your cylinder with Hyva cylinder?

    A: Same inside structure.

    Same outside dimension and same mounting sizes. It can be interchangeable with Hyva's


    Q2. Compared with Hyva cylinder, what are your cylinder advantages?

    A: 1. Rod are chrome plated.

    2. Tubes are quenched and tempered.

    3. Tube inner hole goes through deep hole boring machine processing. Surface roughness is 0.4Ra

    and circular degree is 0.025.

    4. Good quality yet lower price.


    Q3: Are you a manufacture or a trade company?

    A: Manufacture, we are the leader manufacturer of hydraulic industry in China with 22 years' experience and technology accumulation. With strong technical team we could solve any annoyance of you.


    Q4: Do you have quality control system?

    A: Yes, the quality management system introduced is: ISO/TS 16949:2009-certified by NQA and IATF cert.


    Q5: How can i get a booklet and buy a cylinder from you?

    A: Extremely easy! Just leave me a message or email or call me directly, let me know you are interesting in our products. I will talk with you for the details soon!
