Excavator Hollow Bore Double Acting Ram Cylinder Long Stainless Steel

Excavator Hollow Bore Double Acting Ram Cylinder Long Stainless Steel

    • Excavator Hollow Bore Double Acting Ram Cylinder Long Stainless Steel
    • Excavator Hollow Bore Double Acting Ram Cylinder Long Stainless Steel
    • Excavator Hollow Bore Double Acting Ram Cylinder Long Stainless Steel
  • Excavator Hollow Bore Double Acting Ram Cylinder Long Stainless Steel

    Product Details:

    Place of Origin: Shandong China
    Brand Name: DALLAST
    Certification: GS CE ISO 9001
    Model Number: Customized

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: negotiation
    Packaging Details: Carton or According to Customer's Require
    Delivery Time: 15-25 days
    Payment Terms: T/T, Western Union, D/A, D/P, L/C
    Supply Ability: 50000 Pieces/Per year
    Contact Now
    Detailed Product Description
    Usage: Excavator Material: Hard Chrome Piston Rod
    Type: Hydraulic Double Acting Sample: Available
    Maximum Stroke: Requirements Painting: Anti Rust Painting
    High Light:

    double acting hydraulic cylinder

    ,

    double acting ram cylinder

    Excavator Hollow Bore Double Acting Stainless Steel Hydraulic Cylinder Long



    This heavy duty excavator hydraulic oil cylinder has good vibration and shock performance, with reliable sealing and long service life, with good dust-proof and easy maintenance.

    Have good vibration

    With reliable sealing

    Long service life



    Designed For Double-acting
    Max inner tube 170mm,180mm,195mm,200mm,210mm,etc
    Mounting distance 325mm/345mm/425mm or as cutstomers’requirements
    Working Pressure 5-36 Mpa
    Stroke 750mm-12000mm
    Tipping Weight 35-68Ton
    Seal Type Parker,NOK, BUSAK SHAMBAN or as customer's requirement
    Piston Rod Chrome or nickel plated,ground & polished piston rod
    Tube High tensile cold drawn tube, precision honed for extended seal life
    Delivery Time Within 30 days after contract established
    Product Name Excavator hydraulic cylinder





    1. Application: Trailer, excavator, log splitter, hydraulic press, garbage compactor, lift platform, dock leveler....
    2. Installation: Two ends with earring, with flanges, with trunnion, with U clevis, with ball;
    3. Working pressure:5Mpa-36Mpa;
    4. Working temperature: -40~50C;
    5. Cylinder seals: NOK, PARKER, HALLITE.
    6. The thickness of chrome plating: 30-50μm;
    7. Every cylinder will be tested before exporting;
    8. We can also design as per your demand.



    Other information

    Cylinder tube size and choice
    According to the cylinder pressure and inside diameter size, different steel tube Would be chosen.
    1. ID ≤300mm, cold rolled precision seamless tube would be choose
    2. 300mm≤ID ≤500mm, hot rolled seamless tube would be choose
    3. 500mm≤ID ≤1000mm, forged tube would be chosen

    4. Cylinder tube steel grade: SAE1020, SAE1045 ,27SiMn, S355JR, S355J2G3 St52-3, SUS304, SUS316L etc .
    5. Cylinder tube inside boring and honing, roughness R0.2-R0.3,
    6. Cylinder tube inside chromating: if necessary, tube inside cremating could be applied.



    Piston rod is a very important part for hydraulic cylinder.
    1. Piston rod steel grade: SAE1045, 42CrMo4, SUS410, SUS420, SUS304, SUS316L
    2. Piston rod cremating and surface hardness.
    DALLAST company ensure that every piece piston rod would be surface hardened before cremating, surface hardness is HRC55~60, Chromating film thickness is 0.03~0.04mm if there are no other specific requirements.



    Painting and storage.
    After hydraulic cylinder pass through pressure test, painting is necessary.



    Product Advantages:
    1 More than 22 years manufacture experience
    2 Our own factory
    3 ISO9001-2008
    4 Competitive price and high quality
    4 Competitive price and high quality
    5 Based on your drawing or requirement
    6 rigid matching control and proper seals
    7 Easy install and easy maintain



    Dallast is committed to provide hydraulic cylinder and hydraulic assembly components with excellent quality for the global machine manufacturing enterprise. Since the establishment of the company, we carry out the principles of “Honoring contract, Quality service” to the customers with super high-quality products. ‘OEM ODM’ is our formidable backing. Furthermore, we have got the certification of ISO / TS16949-2009. We can ensure the product' quality and provide you with the fastest delivery speed.

    We have our own factories, and engineers, We can customize the product according to your needs.
