Custom Telescopic Hydraulic Ram , 4 Stage Telescopic Cylinder FC FE Type for Truck

Custom Telescopic Hydraulic Ram , 4 Stage Telescopic Cylinder FC FE Type for Truck

    • Custom Telescopic Hydraulic Ram ,  4 Stage Telescopic Cylinder FC FE Type for Truck
    • Custom Telescopic Hydraulic Ram ,  4 Stage Telescopic Cylinder FC FE Type for Truck
    • Custom Telescopic Hydraulic Ram ,  4 Stage Telescopic Cylinder FC FE Type for Truck
  • Custom Telescopic Hydraulic Ram ,  4 Stage Telescopic Cylinder FC FE Type for Truck

    Product Details:

    Place of Origin: Qingdao
    Brand Name: DALLAST
    Certification: GS, RoHS, CE, ISO9001
    Model Number: custom

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pieces
    Price: negotiation
    Packaging Details: wooden case, carton box
    Delivery Time: 15-25 work days per year
    Payment Terms: T/T, Western Union, D/P, D/A, L/C
    Supply Ability: 50000 pieces
    Contact Now
    Detailed Product Description
    Pressure Direction: Single Acting Pressure: 16-35MPa
    Temperature: Normal Or High Temperature HS Code: 8412210000
    OD: Custom ID: Custom
    High Light:

    electric telescopic cylinder

    ,

    elescoping hydraulic ram

    Custom Telescopic Hydraulic Ram , 4 Stage Telescopic Cylinder FC FE Type for Truck



    Application:

    Telescopic cylinders have two or more piston rods in a coaxial arrangement to achieve greater extended length compared to the retracted length. An external force is required to return the cylinder to the retracted position. A typical application for a single-acting cylinder is a lift truck, where the load of the fork pushes the cylinder back.



    Can be used on construction machinery,engineering machinery,mining machinery,lock of water resource project and so on.



    Features:

    Good quality and low noise; the oil way design perfectly and can save the energy, avoid wast.



    When manufacturing multistage cylinders, the number of stages are able to produce, which is limited only by the physical confines of the cylinder requirement.



                                                   FE Type Hydraulic Cylinder
    Model No. Stages Stroke
    (mm)
    Mounting distance
    (mm)

    1st Stage

    diameter

    (mm)

    Operating

    Pressure

    (MPa)

    FE-3-110-3205 3 3205 1449 110 16
    FE-3-110-3460 3 3460 1609 110 16
    FE-3-129-2980 3 2980 1449 129 16
    FE-3-129-3205 3 3205 1609 129 16
    FE-3-149-3460 3 3460 1320 149 16
    FE-3-110-3880 3 3880 1420 110 16
    FE-3-110-4270 3 4270 1520 110 16
    FE-3-110-4280 3 4280 1644 110 16
    FE-4-110-4280 4 4280 1450 110 16
    FE-4-110-5180 4 5180 1644 110 16
    FE-5-169-6830 5 6380 1674 169 16
    FE-5-169-7130 5 7130 1769 169 16
    FE-5-191-6180 5 6180 1527 191 16
    FE-5-191-9030 5 9030 2177 191 16
    FE-6-191-7420 5 7420 1677 191 16



        FC Type Hydraulic Cylinder


    MODEL NO Stage

    Largest Stage

    Diameter

    Stroke

    The largest

     sleeve OD

    Mounting

    distance


    (mm) (mm) (mm) (mm)

    Operating pressure





    (MPa)

    FC-3-110-3205 3 110 3205 168 343 16
    FC-4-169-4940 4 169 4940 244 343 16
    FC-4-169-5180 4 169 5180 244 343 16
    FC-4-169-5460 4 169 5460 244 343 16
    FC-5-169-5355 5 169 5355 244 343 16
    FC-5-169-5780 5 169 5780 244 343 16
    FC-5-169-6180 5 169 6180 244 343 16
    FC-5-169-6830 5 169 6830 244 343 16
    FC-5-169-7130 5 169 7130 244 343 16
    FC-5-169-7630 5 169 7630 244 343 16
    FC-5-169-8130 5 169 8130 244 343 16
    FC-5-169-9030 5 169 9030 244 343 16
    FC-5-169-9530 5 169 9530 244 343 16



    Designed For Single-acting,double-acting
    Stage 3~5stage cylinder
    Max inner tube 170mm,180mm,195mm,200mm,210mm,etc
    Working Pressure 16Mpa-35Mpa
    Tipping Weight 13-90Ton
    Seal Type Parker,NOK, BUSAK SHAMBAN or as customer's requirement
    Piston Rod

    Chrome or nickel plated,ground & polished piston rod

    Technical Treatment: Quenched and tempered. 1.5-1mm, or 1.03mm per millimetre

    Tube High tensile cold drawn tube, precision honed for extended seal life
    Warranty We offer 12 months warranty



    We can OEM & ODM, If you are interested in our hydraulic RAM, please feel free to contact us.

    The drawings:

    The drawing details are as follows.

    A

    1. Bore size

    2. Stroke length

    3. Rod diameter

    4. Mounting type

    5. Mounting length

    6. Paint color requirement



    B. The product application description details

    1. Type of machine(loader, steer loader, excavator, and etc.)

    2. Type of function(hoist, swing, steering, and etc.)

    3. Type of structure(piston, telescopic)

    4. Single or double acting

    5. Operating pressure





    After-sales service:
    1. Various operation instructions such as: products inspect and control ,Receiving inspection control ,sampling inspection operation instruction, process quality inspection operation instruction etc
    2. Pre-sale service and free consultation service.
    3. Quality control service includes pre-acceptance, departure inspection, arrival inspection, PDI delivery inspection.
    4. Guarantee period is subjected to warranty instruction (1 year/ 2000 hours whichever comes first).
    5. Free after-sale service during the warranty refers to problems caused by quality issues; any non quality problem occurred, we will charge the maintenance fee according to relevant standard.
    6. Service Center all over the world for after sales problems.



    Custom Telescopic Hydraulic Ram ,  4 Stage Telescopic Cylinder FC FE Type for Truck

    Custom Telescopic Hydraulic Ram ,  4 Stage Telescopic Cylinder FC FE Type for Truck

    Custom Telescopic Hydraulic Ram ,  4 Stage Telescopic Cylinder FC FE Type for Truck
