Home ProductsSingle Acting Hydraulic Ram

Stainless Dump Single Acting Hydraulic Ram Trailer Pressure ISO 9001 Certification

Stainless Dump Single Acting Hydraulic Ram Trailer Pressure ISO 9001 Certification

    • Stainless Dump Single Acting Hydraulic Ram Trailer  Pressure ISO 9001 Certification
    • Stainless Dump Single Acting Hydraulic Ram Trailer  Pressure ISO 9001 Certification
    • Stainless Dump Single Acting Hydraulic Ram Trailer  Pressure ISO 9001 Certification
  • Stainless Dump Single Acting Hydraulic Ram Trailer  Pressure ISO 9001 Certification

    Product Details:

    Place of Origin: Shandong China
    Brand Name: DALLAST
    Certification: GS CE ISO 9001
    Model Number: Customized

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 piece
    Price: negotiation
    Packaging Details: Carton or According to Customer's Require
    Delivery Time: 15-25 days
    Payment Terms: T/T, Western Union, D/A, D/P, L/C
    Supply Ability: 50000 Pieces/Per year
    Contact Now
    Detailed Product Description
    Sample: Available Factory Visit: Available
    Installation: Front End Loader Place Of Origin: Shandong
    Painting: Anti Rust Painting Piston: High Grade And Precisely Machined Ductile Iron
    High Light:

    single acting telescopic cylinder

    ,

    industrial hydraulic cylinders

    FTop 10 Stainless Dump Trailer Single Acting Hydraulic Cylinder Pressure Manufacturers


    FC type hydraulic cylinder

    MODEL NO. Stage Largest Stage Diameter Stroke The largest sleeve OD Mounting distance
    FC-3-129-4270 3 129 mm 4270mm 218mm 343mm
    FC-4-149-3980 4 149 mm 3980mm 218mm 343mm
    FC-4-169-5460 4 169mm 5460mm 244mm 343mm
    FC-5-169-5355 5 169mm 5355mm 244mm 343mm
    FC-5-169-5780 5 169mm 5780mm 244mm 343mm




    FE type hydraulic cylinder

    Model Stage Largest stage diameter Stroke Mounting distance
    FE-3-110-3205 3 110mm 3205mm 1449mm
    FE-4-169-5000 4 169mm 5000mm 1574mm
    FE-4-169-5180 4 169mm 5180mm 1604mm
    FE-5-169-5355 5 169mm 5355mm 1394mm
    FE-5-169-5780 5 169mm 5780mm 1559mm



    Main feature

    Seal kits Heat treatment Cleaning
    From Usa, durable and hard-wearing to ensure the small hydrualic cylinder a long service life Quenching&Tempering which makes the piston rod super high hardness Ultrasonic cleaning
    Cutting 1year warranty Customized design
    High precision provided by automatic roller cutting machine

    Great quality products
    We stand behind the quality of our products 100%
    All our items come with a warranty to give you a peace of mind


    We not only produce hydraulic cylinder as OEM,but also we are able to design the original drawing for our customer who may not be so familiar the products
    Delivery New Guaranteed MOQ

    Shipment term: CIF/CFR/FOB Qingdao China
    Shipment date: 7-30 days after receiving the deposit
    We will ship your items by sea

    All of our items are in new condition in OEM or Original packing 1 PCS of small hydraulic cylinders



    Characteristic:
    High Speed: Working speed is high, cycle time is short, working capacity is more.
    High Efficiency: Light weight, more loading capacity.
    High Strength: New design, new material.
    - New design products, bigger diameter, more lifting capacity.
    - Max working pressure reaches 190 bars, better anti-pressure ability.
    - Special-purpose material, high quality, high-precision, better anti-bending ability.
    - New model guide ring combined with Senior lubricating material, guarantee cylinder lift more smoothly and work long time.
    - Modified seal structure, guarantee no oil leak under high pressure and bad
    working environments.
    - New model stop collar combined with new model guide ring, maximum limit improve the working security and stability.
    - Equipped with maintenance-free support, longer working life, bring you more benefit.
    - Adopt "Less component integration" design philosophy, easy to maintain.
    - Cylinder is tested 100%, guarantee high quality

    Stainless Dump Single Acting Hydraulic Ram Trailer  Pressure ISO 9001 Certification
